Carbon Fiber RC Helicopter Frame Panel — CFW-3169
A rectangular frame panel with shaped edge features for an RC helicopter assembly. Use the drawing to define mounting locations and clearances.
Enquiry reference: CFW-3169
Made to order · Minimum order: 1 unit
All products are supplied by quotation. Send the product reference, specification, quantity and delivery destination for a tailored quote.
Description
Product description
Carbon Fiber RC Helicopter Frame Panel — CFW-3169. A frame-panel reference for a model helicopter project. Confirm the side-frame geometry and mounting interfaces against the actual model rather than selecting from appearance alone.
Listed configuration: Product form: Frame panel; Material: Carbon fiber laminate.
PRODUCT DETAILS & MANUFACTURING
A closer look
Explore the structural details and manufacturing stages relevant to this product family. The illustrations explain construction; the product gallery and agreed specification define the selected model.
Side-panel spacing
Side-panel holes and spacer connections shown as an assembly detail.
AI-generated structural illustration; not a photograph of this exact model.
Manufacturing overview
- Review the drawing
Review laminate, thickness, outline and hole or slot requirements against the drawing.
- Locate & clamp
Support and secure the stock while keeping the tool path clear.
- Machine contours & features
Machine the required features using tooling and methods suited to the composite.
- Finish edges & inspect
Finish the edges and check critical dimensions and assembly interfaces.
View the illustrated manufacturing process
PRODUCT SPECIFICATION
Configuration & supply details
| Enquiry reference | CFW-3169 |
|---|---|
| Product form | Frame panel |
| Material | Carbon fiber laminate |
| Drawing and dimensions | To the agreed component drawing |
| Supply unit | Individual components or specified sets |
| Minimum order quantity | 1 unit |
| Ordering | Custom quotation; no fixed public price |
Confirm the frame drawing, hole locations, thickness and parts included. The product reference is not an airworthiness or flight-performance claim.
What to specify
- Plate thickness and laminate construction.
- Outline, holes, slots and assembly interfaces.
- Critical dimensions, edge finish and required quantities.
For an accurate quotation
Provide the helicopter model or assembly drawing, panel thickness and critical interfaces.
Include the required quantity and destination. Our team will confirm the agreed specification and scope of supply with the quotation.
RC helicopter workshop
The scene shows a generic small RC helicopter at rest on a hobby bench. It illustrates the component category, not a supplied complete helicopter or a verified fit for this panel.
Quote reference CFW-3169 when sending your requirements.
